Description
CORE COMPONENTS
Power Specs
- 25KW diesel generator
- 50-gallon certified fuel tank
- Four (4) Deep cycle batteries with a cut-off switch
- 30-position breaker panel
- 55-amp battery charger
- 30′ Hubble 100A inlet cable
- Five (5) Rough Neck A/C roof-mounted units
- Three (3) 1500-watt wall heaters
- Two (2) 5000 BTU Wabasto diesel-fired heaters
- Cold weather package
- One (1) Glycol engine heater for the generator
Instrumentation Systems
- Full-height computer rack
- Rack-mounted computers with Windows OS on slides
- UPS back-up system
- Multiple monitors and sizes
- Handheld radios with Dual Muff Headsets
- Stereo w/4 speakers
- CB radio ready
- Roof-mounted Satellite with modem and controller
General
- Unit Dimensions
- Length: 44’-0” (13.4 meters)
- Width: 8’-6” (2.6 meters)
- Height: 13’-6” (4.1 meters)
- Weight: 50,000 Lbs. (22,680 Kg)
- Four (4) post leg stabilizer system
- Electric over hydraulic slide-out room
- Wall divider with pocket door to separate the pump room and lab room from
main area (one at each end of the trailer) - Corian solid surface countertops
- Coffee bar area to house a microwave and under-the-counter coffee maker
- Lighting
- Ten (10) exterior LED work lamps
- Thirty-six (36) 12volt LED (red/clear) cabin lights
- LED light strip behind the computer rack
- 6″strip in each exterior belly box on a magnetic switch
